Sprinkle 3/4-inch Rotary S-36

Sprinkle 3/4-inch Rotary S-36 di TokoRafif

Bahan : Plastik
Ukuran Drat Luar : ¾” inch Drat Dalam/ Female
Jangkauan Siram : 13m s/d 18 m
Tekanan Kerja yang di sarankan : 25-65 PSI (1,75 – 4,5 BAR).
Derajat Siram : Full circle – 360º
Debit Siram : 4 s/d 24 liter / menit
Aplikasi yang di sarankan : holtikultura &Tanaman dengan Ketinggian Sedang

The model S-36 is a sprinkler made ​​of plastic and is considered a medium flow sprinkler with male or female 3/4″ connection. With two nozzles, the main 25º and the secondary also 25° but slotted for short radius. These nozzles can be made of brass (recommended by VYR) or nylon plastic. The spoon has a better counterweights injected to drive rotation.

The S-36 is one of the most standard sprinklers for irrigation worldwide and is commonly used at 49×59 ft. or 59×59 m. frames with 3.5 BAR and working with average flow of 8 GPM.

p.p1 {margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px Helvetica}

It’s widely used in all kinds of field crops: cereals, sugar beet, alfalfa, vegetables, etc.

FEATURES

Medium flow agricultural impact sprinkler.

3/4″ male or female connection.

Made of plastic and stainless steel.

High-resistance rotating joints.

Nozzle angles of 25º and 25º.

Used in full coverage irrigation with the best compliance with spacing standards in the market.

Curved design of the internal angles of the body to avoid internal hydraulic turbulence and for greater reach.

Stainless steel ball counterweights inserted in the arm.

p.p1 {margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px Helvetica}

Plastic sprinkler, leader in the agricultural market.

OPTIONS

Threads in BSP or NPT under demand.

Models with anti-frost cover with male or female connection.

Brass or plastic nozzles, depending on the customer’s technical specifications.

Secondary nozzle with deflector slot or plug.

p.p1 {margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px Helvetica}

Assembled on a pressure regulator for self-compensation of pressure and flow.

APPLICATIONS

This model is compatible with almost any type of crop and with a wide range of pluviometric and spacing conditions, suitable for a large number of different crop types.

p.p1 {margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px Helvetica}

Horticultural plantations, cereals, tubers, leguminous plants and fruit trees.
